的產品主要參數 | Channels | Resolution | DAC Type | TUE Iout (typ) | Output Range | DAC Features | Supply Voltage Range |
|
| bits |
| % |
|
|
|
| AD5423 | 1 | 16 | Current Out, Voltage Out |
| ±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, 0 to 5V, -0.3V to 5.7V, -0.4V to 11.6V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 12V, -1mA to 22mA, 4mA to 20mA | 4-20mA, HART Connectivity | -33V to +33V |
| AD74412R | 4 | 16 | Current Out, Voltage Out | 0.2 | 0mA to 25mA, 0V to 11V | 4-20mA | 14V to 26.4V, 2.7V to 5.5V |
| AD74413R | 4 | 16 | Current Out, Voltage Out | 0.2 | 0mA to 25mA, 0V to 11V | 4-20mA | 14V to 26.4V, 2.7V to 5.5V |
| AD5413 | 1 | 14 | Current Out, Voltage Out |
| ±10.5 V, ±12.6 V, 0mA to 24mA | 4-20mA, HART Connectivity | -33V to +33V |
| AD5758 | 1 | 16 | Current Out, Voltage Out |
| ±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 12V, 0V to 5V, 0V to 6V, -1mA to 22mA, 4mA to 20mA | 4-20mA, DAC, Dynamic Power Control, HART Connectivity, Integrated ADC, LDAC Pin | -33V to 0V, 5V to 33V, 7V to 33V |
| ADFS5758 | 1 | 16 | Current Out, Voltage Out |
| ±10V, ±12V, ±20mA, ±24mA, ±5V, ±6V, -0.3V to 5.7V, -0.4V to 11.6V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 12V, 0V to 5V, 0V to 6V, -1mA to 22mA | 4-20mA, DAC, Functional Safety, HART Connectivity, Precision DACs | -12V to -24V, -33V to +33V |
| AD5735 | 4 | 12 | Current Out, Voltage Out | 0.022 | ±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 5V, 4mA to 20mA | 4-20mA, CLR Pin, Double-Buffered, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | -26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V |
| AD5737 | 4 | 12 | Current Out | 0.022 | 0mA to 20mA, 0mA to 24mA, 4mA to 20mA | 4-20mA, CLR Pin, Double-Buffered, HART Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | 2.7V to 5.5V, 4.5V to 5.5V, 9V to 33V |
| AD5755 | 4 | 16 | Current Out, Voltage Out | 0.009 | ±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 5V, 4mA to 20mA | 4-20mA, CLR Pin, Double-Buffered, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | -26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V |
| AD5755-1 | 4 | 16 | Current Out, Voltage Out | 0.009 | ±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 5V, 4mA to 20mA | 4-20mA, CLR Pin, Double-Buffered, HART Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | -26.4V to -10.8V, 4.5V to 5.5V, 9V to 33V |
| AD5757 | 4 | 16 | Current Out | 0.009 | 0mA to 20mA, 0mA to 24mA, 4mA to 20mA | 4-20mA, CLR Pin, Double-Buffered, HART Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | 4.5V to 5.5V, 9V to 33V |
| AD5421 | 1 | 16 | Current Out | 0.064 | 3.2mA to 24mA, 3.8mA to 21mA, 4mA to 20mA | 4-20mA, Double-Buffered, LDAC Pin, On Chip Temp Sensor, Read-Back, SDO Pin | 5.5V to 52V |
| AD5410 | 1 | 12 | Current Out | 0.08 | 0mA to 20mA, 0mA to 24mA, 4mA to 20mA | 4-20mA, Daisy Chain, HART Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | 10.8V to 60V |
| AD5412 | 1 | 12 | Current Out, Voltage Out | 0.08 | ±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 5V, 4mA to 20mA | 4-20mA, Daisy Chain, HART Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | 10.8V to 40V, -26.4V to 0V |
| AD5420 | 1 | 16 | Current Out | 0.08 | 0mA to 20mA, 0mA to 24mA, 4mA to 20mA | 4-20mA, Daisy Chain, HART Connectivity, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | 10.8V to 60V |
| AD5422 | 1 | 16 | Current Out, Voltage Out | 0.08 | ±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 5V, 4mA to 20mA | 4-20mA, Daisy Chain, LDAC Pin, Read-Back, Reset/Clear, SDO Pin | 10.8V to 40V, -26.4V to 0V |
| AD421 | 1 | 16 | Current Out |
| 4mA to 20mA | 4-20mA | 2.95V to 5.05V |
| AD420 | 1 | 16 | Current Out, Voltage Out |
| ±10V, ±5V, 0mA to 20mA, 0mA to 24mA, 0V to 10V, 0V to 5V, 4mA to 20mA | 4-20mA | 12V to 32V |
